| SPM I m a g e G a l l e r y | |||||||||||||||||||||||||||||||
| Examples of SPM images taken with help of AFM NT-206 | |||||
|
|||||
| Images have been visualized in SurfaceView | |||||
| Non-structured self assembled polymer (PS) layer on Si substrate | |
|
|
 |
 |
Contact mode, probes Mikromasch CSC12E Top
left: scan size 8.4x8.4 um |
|
|
| Carbon nanotube | Carbon nanotubes |
 |
|
| Tapping
mode. Probe Mikromasch NSC11B. Scan size 1.6x1.6 um. |
|
| DLC coating after friction | Erythrocyte |
 |
|
| Mixed
3D image. 3D Frame: topography. Skin: phase shift. Tapping mode. Probe Mikromasch
NSC11B. Scan size 1.6x1.6 um. |
Tapping
mode. Probe Mikromasch NSC11B. Scan size 7.9x7.9 um. |
| Damage in optical glass | |
 |
|
| Contact
mode. Probe Mikromasch CSC38 B. Scan size 6.1x6.1 um. |
Contact
mode. Probe Mikromasch CSC38 B. Scan size 15.5x11.8 um. |
| Cells subjected to cancer | |
 |
|
| Contact
mode. Probe Mikromasch CSC38 B. Scan size 19.6x19.6 um. |
Contact
mode. Probe Mikromasch CSC38 B. Scan size 10.2x10.2 um. |
 |
|
| Contact
mode. Probe Mikromasch CSC38 B. Scan size 33x33 um. |
Contact
mode. Probe Mikromasch CSC38 B. Scan size 19.9x19.9 um. |
| Surface of a CD | Surface of a CDRW |
 |
 |
| Contact mode. Probes Mikromasch CSC12E. Scan size 5*5 um | Contact mode. Probes Mikromasch CSC12F. Scan size 5*5 um |
 |
 |
| Contact mode. Probes Mikromasch CSC12E. Scan size 12*12 um | Tappimg mode. Probes Mikromasch CSC12F. Scan size 5*5 um |
 |
|
| Mixed image: Phase image as skin for 3D topography image (blue - soft material, yellow - harder substarte). Tappimg mode. Probes Mikromasch CSC12F. Scan size 2*2 um | |
| Rubber | |
 |
|
| Tapping
mode. Probe Mikromasch NSC11B. Scan size 7.6x7.6 um. |
Tapping
mode. Probe Mikromasch NSC11B. Scan size 1.6x1.6 um. |
| Cellulose | |
|
|
|
| Phase shift image of the topography from right. Dynamic mode. Probes: Mikromasch NSC11A. Scan size 1.5x1.5 um | Topography
image. Dynamic mode. Probes: Mikromasch NSC11A |
 |
|
| Mixed
image of above two ones (3D topography frame with skin according to phase image). |
Mixed 3D image. Frame: topography. Skin: phase shift. Probes Mikromasch NSC11A. Scan size 1.3x1.3 um |
| IC structure | |
 |
 |
| Nanoimprinting mold | PPK resist |
 |
|
| Topography
image. Contact mode. Probes: Mikromasch CSC38B. Scan size: 25.4x25.4 um |
|
| Silicon substrate of microchip | |
 |
 |
|
|
